330009 Torus v1.0



10,48

This is the coarsest NURBS solid model of a torus.

Categories: ,
Tags: ,

Description

This is the coarsest NURBS solid model of a torus.

Specifications
Product ID 330009
Published June 18, 2018
Size 1.16 MB
Product Type Image
Model NURBS
Degree (ξ) 2
Degree (η) 1
Degree (ζ) 2
Control Points (ξ) 9
Control Points (η) 2
Control Points (ζ) 9
Control Points 162
Knot Spans (ξ) 4
Knot Spans (η) 1
Knot Spans (ζ) 4
Elements 16

Files

This pack includes all the following images of the NURBS model obtained using Geomiso, which depict the geometry, the control net, the control points and the knot lines.
