220021 Annulus v1.0



8,06

This is the coarsest NURBS surface model of an annulus with outer/inner radius R1/R2 (R1>R2, R2≠0).

Categories: ,
Tags: ,

Description

This is the coarsest NURBS surface model of an annulus with outer/inner radius R1/R(R1>R2, R2≠0).

Specifications
Product ID 220021
Published June 12, 2018
Size 206 KB
Product Type Model
Model NURBS
Degree (ξ) 2
Degree (η) 1
Control Points (ξ) 9
Control Points (η) 2
Control Points 18
Knot Spans (ξ) 4
Knot Spans (η) 1
Elements 4

Files

This pack includes all the following files, which contain the control variables and the knot vectors required to produce the NURBS model using Geomiso or any other NURBS-based software.

  •  PDF file (220021 Annulus Description.pdf, 98 KB)
  •  Microsoft Excel file (220021 Annulus Control Variables.xlsx, 12 KB)
  •  Microsoft WordPad file (220021 Annulus Control Variables.rtf, 1 KB)
  •  Microsoft Notepad file (220021 Annulus Control Variables.txt, 1 KB)
  •  Images (4 png files, 1920×964 pixels, 93 KB)
