320001 Square v1.0



0,80

This is the coarsest linear/ quadratic/ cubic NURBS surface model of a square.

Categories: ,
Tags: , , , ,

Description

This is the coarsest linear/ quadratic/ cubic NURBS surface model of a square.

Specifications
Product ID 320001
Published June 17, 2018
Size 157 KB
Product Type Image
Model NURBS
Degree (ξ) 1/2/3
Degree (η) 1/2/3
Control Points (ξ) 2/3/4
Control Points (η) 2/3/4
Control Points 4/9/16
Knot Spans (ξ) 1
Knot Spans (η) 1
Elements 1

Files

This pack includes all the following images of the NURBS model obtained using Geomiso, which depict the geometry, the control net, the control points and the knot lines.
