330004 Square Pyramid v1.0



3,62

This is the coarsest linear/ quadratic/ cubic NURBS solid model of a regular pyramid with square base.

Description

This is the coarsest linear/ quadratic/ cubic NURBS solid model of a regular pyramid with square base.

Specifications
Product ID 330004
Published June 18, 2018
Size 1.17 MB
Product Type Image
Model NURBS
Degree (ξ) 1/2/3
Degree (η) 1/2/3
Degree (ζ) 1/2/3
Control Points (ξ) 2/3/4
Control Points (η) 2/3/4
Control Points (ζ) 2/3/4
Control Points 8/27/64
Knot Spans (ξ) 1
Knot Spans (η) 1
Knot Spans (ζ) 1
Elements 1

Files

This pack includes all the following images of the NURBS model obtained using Geomiso, which depict the geometry, the control net, the control points and the knot lines.
