220019 Circular Disk (Triangle) v1.0


5,64

This is the coarsest NURBS surface model of a circular disk with radius R inscribed in a triangle.

Categories: ,
Tags: , ,

Description

This is the coarsest NURBS surface model of a circular disk with radius R inscribed in a triangle.

Specifications
Product ID 220019
Published June 12, 2018
Size 181 KB
Product Type Model
Model NURBS
Degree (ξ) 2
Degree (η) 1
Control Points (ξ) 7
Control Points (η) 2
Control Points 14
Knot Spans (ξ) 3
Knot Spans (η) 1
Elements 3

Files

This pack includes all the following files, which contain the control variables and the knot vectors required to produce the NURBS model using Geomiso or any other NURBS-based software.

  •  PDF file (220019 Circular Disk (Triangle) Description.pdf, 60 KB)
  •  Microsoft Excel file (220019 Circular Disk (Triangle) Control Variables.xlsx, 12 KB)
  •  Microsoft WordPad file (220019 Circular Disk (Triangle) Control Variables.rtf, 1 KB)
  •  Microsoft Notepad file (220019 Circular Disk (Triangle) Control Variables.txt, 1 KB)
  •  Images (4 png files, 1920×964 pixels, 106 KB)
